SMT
UniS-L LED Illumination Inspector
Equipment to inspect the lighting condition and quality of LED products
Key Features
-Establish a stable environment by supplying accurate current and voltage using the lighting jig
-Provides a recipe function that allows you to set inspection criteria for various types of LED substrates, making flexible inspection of different types of LED products
-Automated conveyor logistics can be applied to quickly inspect large quantities of products, suitable for large production lines
-Provides a recipe function that allows you to set inspection criteria for various types of LED substrates, making flexible inspection of different types of LED products
-Automated conveyor logistics can be applied to quickly inspect large quantities of products, suitable for large production lines
Product Specifications
Category | Specification |
Camera | 10M |
FOV | 350 x 300 mm |
Resolution | 100 ㎛/pixel |
Inspection Time | 2.0s @ 1 PCB Sheet 350x300mm (Excluding transportation time) |
Board Jig | Customizing |
Inspection Item | LED light defect : Dim light / Brightness not uniform |
Option | OLTT (Off-Line Teaching Tool Software) Barcode System / Auto width conveyor |
