Customizing Vision
Motor visual Inspection
Precisely inspect the manufacturing dimensions of the visual inspection machine motor and defects such as scratches, cracks, foreign substances, discoloration, etc. on the outside of the motor
Key Features
-Perform quick and consistent quality inspection through automated inspection process, automatically classifying good and bad products after inspection, and efficient inspection
-Turn the motor and inspect the exterior from 360 degrees in all directions to inspect the entire condition without blind spots
-Turn the motor and inspect the exterior from 360 degrees in all directions to inspect the entire condition without blind spots
Product Specifications
Category | Visual | Measurement | Note |
Camera | 2K Line Scan | 12M Area Scan | |
FOV | 38 mm | 80mm X 60mm | |
Resolution | 18 ㎛/pixel | 20 ㎛/pixel | |
Tact Time | 7sec | ||
Light System | High-brightness LED Light | ||
Inspection Item | cracks, foreign objects, scratches, and marks | 6-Point Dimensions Measurement (Settings) | |
Option | |||
